Latest run

The Latest run section shows the status and mode of the latest run that was executed.

Latest run status showing 'Pending' with 0% progress and execution mode 'Online - Paired' — Figure 1. Latest run

Current status

This shows the current status of the latest run. A percentage value will show.

Execution mode

This shows the current execution mode and connectivity status.

Not available - while not running.

Disconnected - while in Offline mode.

Sending - standard behavior, data goes upstream.

Sending, Buffering - data is being sent and buffering is happening due to incoming data.

Sending, Dropping - data is being sent and dropped because incoming data and buffering limits were reached.

Disconnected (never connected) - network was absent before Arc could ever connect to the upstream.

Buffering (never connected) - network was absent before Arc could ever connect to the upstream: buffering started due to incoming data.

Dropping (never connected) - network was absent before Arc could ever connect to the upstream: dropping started due to reaching buffering limits.

Disconnected (last connection at dd-mm-yyyy hh:mm:ss) - network was absent since the indicated time.

Buffering (last connection at dd-mm-yyyy hh:mm:ss) - network was absent since the indicated time: buffering started due to incoming data.

Dropping (last connection at dd-mm-yyyy hh:mm:ss) - network was absent since the indicated time: dropping started due to incoming data and buffering limits were reached.
