Benchmark management

The Benchmark management tab lists the benchmarks available on this Arc sensor.

Benchmark management tab in the Arc local UI, showing no benchmarks on this sensor and the disabled Upload button — Figure 1. Benchmark management page

For more details, see Compliance benchmarks.

The Benchmark management page is read-only: you cannot upload or delete benchmarks from Arc. Benchmarks are managed from the upstream system, and you can upload them only from Vantage. Arc stores benchmark files locally.

Column descriptions

The Rules, Published at, and Uploaded at columns are hidden by default.

Column label	Description
Benchmark name	The name of the benchmark.
Source	Which system provided the benchmark. In Vantage: provided by DISA (DISA) or uploaded by a user (Users). On Arc: uploaded on this sensor (Local) or fetched from the upstream system that manages this sensor (Remote).
Version	The version of the benchmark.
Category	The category of the benchmark, for example Operating System, Application, or Network Device.
Platform	The operating system (OS) family the benchmark applies to, for example Windows or Linux.
Rules	The number of rules in the benchmark.
Policies	The policies that use this benchmark. Select View JSON to see the full list.
Published at	The date the benchmark was published by its issuing body.
Uploaded at	When the benchmark was uploaded.
Uploaded by	The name of the user who uploaded the benchmark, or Update Service for Nozomi Networks-provided benchmarks. This column is shown in Vantage only; the Arc Benchmark management page does not include it.
